KRC9 Professional Irrigation Controller

9 Zones

The KRC9 Professional Irrigation Controller covers a wide range of applications from residential and commercial turf, to light agriculture and professional nurseries. Available for 1-9 station configurations, this irrigation controller has advanced features to suit all types of watering.

The individual stations can be allocated to one or all five programs, allowing you to seamlessly integrate your watering applications into one controller.

  • Flexible programming with up to 9 zones, 5 programs and 8 start times
  • Permanent memory – “Never lose your programs”
  • Water saving budgets allow run time adjustment by 10-200% per month
  • Manual and automatic functions
  • Zone watering run time up to 12 hours 59 minutes
  • 5 Year Trade Warranty

⚠ WARNING – Keep new or used button/coin batteries out of reach of children.
Product contains a Button or Coin cell battery. The Battery can cause severe or fatal injuries in 2 hours or less if it is swallowed or placed inside any part of the body. If suspected the battery has been swallowed or otherwise placed inside any part of the body, contact the Australian Poisons Information Centre on 13 11 26 immediately for 24/7 fast, expert advice.

SKUKRC9 Category
Close
Additional information
Weight1.680 kg
Dimensions18 × 7.5 × 21 cm
Close
Specifications

Specifications

Electrical Specifications

  • Internal Transformer
  • Reduces 240VAC to extra low voltage supply of 24VAC

Electrical Outputs

  • Maximum of 1 AMP
  • To the Solenoid Valves: 24 VAC 50/60 Hz 0.75 Amps maximum
  • To the Master Valve/Pump Start: 24 VAC 0.25 Amps maximum

Overload Protection

  • Standard 20mm 1 AMP fuse with faulty station skip function

Power Failure

  • The controller has permanent memory and real time clock, so the data is always backed up even with the absence of all power
  • The unit is factory fitted with a 3V CR2032 lithium battery with up to 10 years memory backup
  • The 9V alkaline battery maintains the data during power outages, and is recommended to help maintain the life of the lithium battery
Close
Instructions

Instructions

View Manual

Close
Reviews

Features:

  • Flexible programming with up to 9 watering zones, 5 programs and 8 start times
  • Permanent memory with real-time clock so you never lose your programs
  • Program in seconds and apply delays for misting, greenhouses and propagation
  • Comply to water restrictions with individual day selection, even/odd/odd-31 and 1-15 day interval watering
  • Manual and automatic functions
  • Rain sensor ready to allow for automatic station delays in wet weather (sold separately)
  • Program to meet water restrictions *

* Programming abilities are subject to your local water authority — be sure to consult them for current watering restrictions.

KRC9 9 zone irrigation controller packaging
