Performance Data
Performance Data
Download Rotary Nozzle Performance Data
Arc | Pressure (kPa) | Radius (m) | Flow Rate (L/min) | Precip. (mm/hour) |
---|---|---|---|---|
90° | 207 241 276 310 345 | 4.88 5.19 5.49 5.80 5.80 | 1.29 1.44 1.55 1.59 1.78 | 15 15 14 13 15 |
180° | 207 241 276 310 345 | 4.88 5.19 5.49 5.80 5.80 | 2.54 2.84 3.14 3.18 3.56 | 15 14 13 15 15 |
270° | 207 241 276 310 345 | 4.88 5.19 5.49 5.49 5.80 | 3.82 4.28 4.69 4.77 5.34 | 15 15 14 15 15 |
