Spray nozzles are important, but often an overlooked component of a well-designed irrigation system. The proper nozzle ensures accurate, even delivery of water in the pattern you need. Male Thread fixed Nozzles have matched precipitation for even water distribution. Available in six fixed patterns, providing an array of system configurations. Extra long filters provide longer time between cleanings.
Download Full Performance Data
| Pattern | Pressure (kPa) | Radius (m) | Flow Rate (L/min) | Precip. (mm/hour) / |
|---|---|---|---|---|
| 90° | 138 170 275 345 | 3.4 3.7 4.0 4.3 | 1.89 2.65 3.03 3.41 | 40 / 47 47 / 55 46 / 53 45 / 52 |
| 180° | 138 170 275 345 | 3.4 3.7 4.0 4.3 | 4.54 5.30 6.44 7.57 | 32 / 37 32 / 37 33 / 38 33 / 38 |
| 360° | 138 170 275 345 | 3.4 3.7 4.0 4.3 | 6.06 6.81 7.95 9.08 | 32 / 37 31 / 35 30 / 35 30 / 35 |
Male Thread Fixed Pattern Spray Nozzles deliver superior matched precipitation for the most popular arc settings. Carefully designed to provided superior coverage while minimizing wind drift, our nozzles feature patterns with precise edges.
| Code | Description | Throw | Spray | Quantity |
|---|---|---|---|---|
| KNM12Q | 12′ Male Thread | 3.6m | 90° Quarter Spray | 1 |
| KNM12H | 12′ Male Thread | 3.6m | 180° Half Spray | 1 |
| KNM12F | 12′ Male Thread | 3.6m | 360° Full Spray | 1 |
| KNM15Q | 15′ Male Thread | 4.5m | 90° Quarter Spray | 1 |
| KNM15H | 15′ Male Thread | 4.5m | 180° Half Spray | 1 |
| KNM15F | 15′ Male Thread | 4.5m | 360° Full Spray | 1 |
